T-HANDLE DEPTH CONTROL
T-handles offer 18 different positions for accurate depth control.
PRESS WHEEL OPTIONS
Choices include, from left, single 3"x13" double rib* press wheels; single 3"x13" center rib press wheels; single 2"x13" smooth press wheels; 1"x12" double-V press wheels; and wedge-style press wheels that create a pinching action to close the trench.
MODULAR DESIGN ALLOWS UP TO THREE BOXES ON A UNIT
This allows three different seeds to be planted at separate rates and different depths at the same time. Optional boxes include native grass or fertilizer, and small seeds.
LEAD COULTER OPTIONS
Choose between a wide ¾" wavy blade, a 5/8" Turbo coulter blade that is aggressive and prepares a mini seedbed ahead of the opener, or a 5/16" fluted coulter blade that penetrates easily to perform minimum tillage.
INTEGRATED WEIGHT BRACKETS
Allow you to easily add weight for better penetration in tough no-till conditions.
Lets you service all the coulter pivot components from two locations.
END WHEEL DRIVE
Large end wheels provide excellent ground drive to the seed meters. Lockout hubs save drive components from wear.
Changing seed rates is quick and effortless with these permanently lubricated, sealed gearboxes.
06 SERIES OPENER
The 06 Series row unit utilizes the “Fluff and Plant” no-till system with an integrally-mounted coulter that cuts residue and prepares a mini seedbed for the trailing double-disc opener. Opener discs are 13.5" in diameter with 4mm-thick blades, 205 triple-lip sealed bearings, and a ¼" opener disc lead. Our unique seed tube design and trailing flap control the seed all the way to the bottom of the seed trench where the seed stays in place.
