Great Plains BD7600-26
BD7600 Box Drill BD7600-26
Overview:
Great Plains has revolutionized the folding box drill once again to give large-scale operations maximum productivity and efficiency in the field. The BD7600 features a new split-box configuration and a larger capacity — up to 3.8 bu./ft. Newly designed feeder cups handle all types of seed and fertilizer with greater ac... + Read More
Features
STURDY BOX DESIGN & STRUCTURE
The updated frame and seed boxes demonstrate industry-leading durability and flexibility. Seed boxes have more capacity and a new geometry allowing them to be filled completely without moving any seed by hand.
OOHD SERIES OPENER
The 00HD Series opener is “beefed up” with a stronger opener body and heavier down-pressure springs than the standard 00 Series. Its 15", 4mm blades are offset ½" for better penetration in harsher field conditions.
GREAT PLAINS METERING SYSTEM
The Great Plains Metering System on the BD7600 Series Drills allows producers to meter large seed, small seeds, and fertilizer — all through the main box of the drill. Feeder cups have been rigorously tested for durability and designed to meter all types of seeds and fertilizer with greater accuracy and easier calibration to save producers both time and money. A host of features makes this feeder cup the most innovative feeder cup available on the market today.
DRILLCOMMAND®
DrillCommand brings a new level of accuracy, convenience, and functionality to Great Plains BD7600 Box Drills. Intuitive and easy-to-navigate buttons with simple-to-understand icons make using this software quick and unintimidating. This option works with most ISOBUS compatible monitors, including Mueller, Topcon, Trimble, Ag Leader, John Deere, and Tellus Pro.
HYDRAULIC DRIVE SYSTEM
This optional drive system streamlines operation with DrillCommand®, an easy-to-use ISOBUS-compatible interface that puts the control of the drill at your fingertips. This industry-leading technology provides automatic section control and variable-rate capabilities while simplifying operation and calibration.
PRESS WHEEL OPTIONS
Choose from the all-new 3"x 13" double rib, 3"x13" center rib, 2"x13" smooth, 3"x14" peak, 1"x12" double V, or 1.25"x13" double wedge-style press wheels (7½" or 10" spacings only).
ALTERNATING LEADING EDGE OPENER BLADES
The opener disc blades are offset, with alternating leading edges to enhance stability and reduce side-shifting for greater precision.
T-HANDLE DEPTH CONTROL
T-handle offers 18 different positions for simple adjustments and accurate depth control.
Specifications
| MODEL INFO | 26'-40' FOLDING MIN-TILL DRILLS |
| MODELS | BD7600-26 |
| TYPE | 2-Section Folding |
| PRIMARY DESIGN | Min-Till |
| ROW SPACING | 6", 7.5", 10" (15, 17, 25 cm) |
| NUMBER OF OPENERS | 52 - 6", 42 - 7.5", 32 - 10" |
| TIRE SIZE | 305/60B16.5 Skid Steer (wing) 385/60B17.5 6.5 Skid Steer (axle) |
| ENGINE H.P. REQUIREMENTS (min) | 112+ |
| WEIGHT (approx. range) | 13,463-15,083 | 14,781-16,781 (6,107-6,842 kg | 6,705-7,612 kg) |
| DIMENSIONS | |
| WORKING WIDTH | 26' 5" (8.05 m) |
| WIDTH (transport) | 16' (4.88 m) |
| LENGTH (transport) | 26' 4" (8.03 m) |
| CLEARANCE (transport) | 1' 5" (43 cm) |
| HEIGHT (transport) | 8' 1" (2.46 m) |
| OPENER SERIES | 00 Series | 00HD Series |
| COULTER | N/A |
| CAPACITIES | |
| MAIN BOX CAPACITY | 101.0 bu (3559 liters) |
| FERTILIZER | up to 45% of seed box |
