E-Z Go RXV
Features
Setting the Pace
Learn how Pace technology drives the game forward on the greens and behind the scenes. Keep your course running smoothly and find new ways to elevate both your bottom line and your guest experience with endless features and premier partnerships.
RXV Highlights
See why the RXV is sure to be your golfers' favorite golf cart.
Golf-Centric Dash
Redesigned dashboard for a more streamlined playing experience.
Hanging Pedals with IntelliBrake™
We've added automotive-style pedals with a built-in parking brake, providing improved durability and comfort. Intellibrake™ available on ELiTE only.
Industry's Largest Bagwell
Golfers have easy access to ample club and bag storage.
New Modular Canopy
Even when it rains, the modular canopy will keep the drive dry. It features a sleek new design with a built-in water management system and integrated hands grips.
Freedom RXV Powertrain Options
Choose between two efficient, hassle-free powertrain options for your fleet.
ELiTE Lithium
Our ELiTE Lithium battery is powered by trusted Samsung SDI technology. This maintenance-free powertrain is so reliable, we offer an unbeatable 8-year warranty.
EX1 Gas Engine
The EX1 is a first-of-its-kind, purpose-built, closed-loop, EFI gas engine. It offers best-in-class fuel economy and will elevate your ride.
Specifications
| RXV Specifications | EX1 Gas | ELiTE™ Lithium |
| Dimensions | ||
| Overall Length | 94.5 in (240 cm) | 94.5 In (240 cm) |
| Overall Width | 47.0 in (119 cm) | 47.0 in (119 cm) |
| Overall Height (w/o roof) | 47.5 in (121 cm) | 47.5 in (121 cm) |
| Overall Height (w/ roof) | 70.0 in (178 cm) | 70.0 in (178 cm) |
| Wheel Base | 65.7 in (167 cm) | 65.7 in (167 cm) |
| Front Wheel Track | 35.5 in (90 cm) | 35.5 in (90 cm) |
| Rear Wheel Track | 38.0 in (97 cm) | 38.0 in (97 cm) |
| Ground Clearance | 4.0 in (10 cm) | 4.0 in (10 cm) |
| Power | ||
| Power Source | Single Cylinder OHC, 4 Cycle, 9.15 cu in (150 cc) | 56 Volts AC |
| Horsepower (KW) | 11.5 hp (8.6 kW) J1995 Standard | 4.4 hp (3.3 kW) Continuous |
| Electrical System | Brushless DC Internal Starter Generator | 56 Volt |
| Batteries (qty/type) | One, 12-Volt Maintenance-Free | ELiTE 2.0, 56V Lithium |
| Key or Pedal Start | Pedal | Pedal |
| Battery Charger | N/A | Lithium World Charger 56VDC (11 ft., 18 ft.) Cord |
| Speed Controller | N/A | 235 Amp AC Controller |
| Drivetrain | Continuously Variable Transmission (CVT) | Motor Shaft Direct Drive |
| Transaxle | Differential W/ Helical Gears | Limited Slip Differential |
| Gear Selection | Forward-Reverse | Dash Mounted Forward-Neutral-Reverse |
| Rear Axle Ratio | 11:47:1 (Forward) 14:35:1 (Reverse) | 16.99:1 |
| Performance | ||
| Seating Capacity | 2 or 4 Passenger | 2 or 4 Passenger |
| Dry Weight | 676 lb (307 kg) | 605 lb (275 kg) (Without Batteries) |
| Curb Weight | 692 lb (314 kg) | 655 lb (298 kg) (With two Li-Ion Modules) |
| Vehicle Load Capacity | 500-800 lb (227-360 kg) | 500-800 lb (227-360 kg) |
| Outside Clearing Circle | 19.0 ft (5.8 m) | 19.2 ft (5.8 m) |
| Speed (Level Ground) | 19 mph ± 0.5 mph (31 kph ± 0.8 kph) | 17.5-19.5 mph (28-31 kph) |
| Steering & Suspension | ||
| Steering | Double-Ended Rack and Pinion | Double-Ended Rack and Pinion |
| Suspension | Front: Independent A-Arm Coil-Over Shock; | Front: Independent A-Arm Coil-Over Shock; |
| Service Brake | Rear Wheel Mechanical Self-Adjusting Drums | Induction Motor |
| Parking Brake | Self-Compensating, Single Point Engagement | Automatic Electro-Magnetic |
| Tires | 18 x 8.50-8 (4-ply rated) | 18 x 8.50-8 (4-ply rated) |
| Body & Chassis | ||
| Frame | Welded Steel with Powder-Coat Protection | Welded Steel with Powder-Coat Protection |
| Body & Finish | Injection Molded TPO | Injection Molded TPO |
| Available Body Colors | Forest Green, Almond, Black, Bright White, Burgundy, Inferno Red, Ivory, Metallic Charcoal, Ocean Grey, Platinum, Patriot Blue, Slate | Forest Green, Almond, Black, Bright White, Burgundy, Inferno Red, Ivory, Metallic Charcoal, Ocean Grey, Platinum, Patriot Blue, Slate |
| Available Seat Colors | Stone Beige, Grey, Black | Stone Beige, Grey, Black |
| Available Premium Seat Colors | Mushroom, Grey, Black, White (custom colors also available) | Mushroom, Grey, Black, White (custom colors also available) |
